KEY FEATURES
High VPN throughput, end-to-end encryption between TOSIBOX® devices, users and servers
Integrated WiFi as connectivity method or access point for wireless devices on site
Built-in global LTE modem – no external modem needed
TosiOnline™ automatic reconnection of dropped connections
Robust and fanless enclosure, DIN rail attachment
CONNECTIONS
9-35V DC
1 x WiFi antenna connector, RP-SMA Male
1 x LTE antenna connector, SMA Female
DIN rail attachment (back)
Maximum power consumption 10W
PHYSICAL PROPERTIES
104 mm x 28 mm x 110 mm / 4.09” x 1.10” x 4.33” (L x W x H)
Storage temperature -30 °C … +70 °C / -22 °F … +158 °F
Protection class IP30
Weight 305 g / 0.67 lbs (net weight article)
Operating temperature -20 °C … +55 °C / -4 °F … +131 °F
General
- Model
- TBL175
- Form factor
- Desktop
- Data transfer speed
- 10 Mbit/s
- Managed
- Yes
- VPN Tunnels
- 10 pcs.
WiFi
- WiFi
- Yes
Ports
- WAN
- 1 pcs.
- LAN
- 1 pcs.
Dimensions and Weight
- Width
- 104 mm
- Height
- 28 mm
- Depth
- 110 mm
- Weight
- 305 g
Packaging info
- Packaging size
- 256 x 136 x 65 mm
- Packaging weight
- 643 g
