The Media Engine ME57U is a low-range media player with two outputs and a compact design. This media engine is created for simple signage which runs 1x UHD (4K) @60Hz.
- 7th Generation Intel® Core™, available in i3 and i5
- 1 x UHD (4K) @60Hz (1x via miniDP) or 2 x UHD (4K) @30Hz (1 x via miniDP and 1 x via HDMI) HEVC/ H.265 & VP9 high-definition playback (hardware accelerated)
- Compact size
- 24/ 7 Operation
UHD (4K) Content playback
This media player is capable of driving UHD (4k) content. With a resolution that goes up to 3840x2160 pixels your content will be close to perfect. This feature marks the players that are capable of delivering content that is fluent and stutter free in UHD (4k).
Reliable high-end computing, low power consumption
This Media engine is created for 24/7 use. It is actively cooled with a fan and ensures low power consumption. Combine this feature with a long lifecycle and you will see why this Media Engine will lower your Total Cost of Ownership (TCO).
Dual Output player
Dual output player, for dual display solutions. These value or mid-range computing devices have multiple outputs, and are therefore perfect for digital signage and dual screen kiosks.
Integrated HEVC/H.265 10bit Codec
These units support native hardware decoding for modern codecs like the HEVC/H265 10 bit. Offloading the CPU, the GPU handles the decoding of the video. This creates a fluent playback up to 60fps.
Processor
- CPU Model
- Intel Core i5-7200U
Memory
- Memory
- 8 GB 2x 4 GB
- Memory Type
- DDR4 SO-DIMM
- Max Memory Supported
- 32 GB depending on OS
- Memory slots
- 2 pcs.
Graphics
- GPU Model
- HD Graphics 620
- Display Connections
- 2 pcs.
Storage
- Storage type
- 2.5" SATA HDD/SSD x1, M.2 SSD x1
- Storage size
- 128 GB
Connections
- HDMI
- Yes 1.4
- DisplayPort
- Yes Mini DisplayPort
- USB type-A
- Yes x3
- USB type-C
- Yes
Communication
- Ethernet
- Yes 10/100/1000 Mbps
Energy
- Power Supply
- 100-240V External Power Supply, 65W (19V, 3.42A) AC Adapter
Dimensions and weight
- Width
- 210 mm
- Depth
- 113 mm
- Height
- 40 mm
- Net weight
- 1.29 kg
Additional Information
- Warranty
- 1 years
Packaging info
- Packaging size
- 130 x 140 x 115 mm
- Packaging weight
- 1.57 kg
