LC300 - CaptureVision System
4-Channel Recorder and Streaming Media Processor with UltraHD and NDI

  • Supports 4 video and 7 audio channels
  • HDMI, USB, SDI, IP, NDI High Bandwidth, NDI HX2 and NDI HX3 inputs
  • HDMI, USB, IP and NDI High Bandwidth outputs
  • USB Output (UVC/UAC) for use in video conferencing
  • Dual Ethernet ports for WAN and LAN integration

Flexible Encoding Performance
LC300 can encode four inputs at 1080 50/ 60P as well as the program output. This gives it powerful recording and streaming capabilities, making it well suited for multi-camera production, interactive media, evidential archiving and enriched digital learning.

Multiple Screen Select
Outputting multiple streams simultaneously, LC300 can work with immersive video platforms. This allows the viewer to control their viewing angle, to focus on a particular presenter, or to switch to a media presentation in real-time.

Intelligent Director (Automated Production)
Intelligent Director automates production, whether it's a meeting room, class room, lecture hall or conference center. This function recognizes the behavior of the presenter and the audience and intelligently changes the camera angle to deliver a TV-like experience. AI-powered, the LC300 works in tandem with Lumense selected tracking cameras to create a multi-angle production without the need for a video crew.

NDI Eco-system
LC300 can serve as a video source switcher in an NDI eco-system, or an AV bridge that converts NDI with HDMI or USB out. It can also push video and audio to multiple streaming platforms at the same time.

Friendly Director User Interface
LC300 is feature-rich and capable of producing stunning results. The device can be managed and controlled locally or remotely, and in conjunction with third-party applications such as Panopto and Kaltura. The local interface available via HDMI is slick and highly visual, giving previews of every source, mix effects and titles, as well as the program output.



General

Model
LC300
Utök. text för namn
4ch Recorder and Streaming Media Processor with UltraHD & NDI

Image specification

Resolution
3840x2160 Out

Connections

Video in
3G-SDI x1
Video in
HDMI x4 (HDMI 2.0 x1, HDMI 1.3 x3)
Video in
IP stream (RJ-45) RTSP Source (HEVC / H.264)
Video in
NDI (RJ-45) NDI HX2, NDI HX3 Source
Video in
USB-A USB Camera (MJPEG 1080p 30fps)
Video out
HDMI x2
Video out
USB-B UVC (up to 1080p)

Energy

Power Supply
DC In , DC In , 19V / 6.8A, Max consumption 130W

Measurements and weight

Width
422 mm
Depth
215.5 mm
Height
65.5 mm
Net weight
3.5 kg

Various

Mounting
19" Rack, 1U
Included Accessories
Power adapter, power cord, USB 3.0 cable 2m (Type B-A), RS-232 connector (x2), Mounting metal plate (x2), Mounting screews, Cable holders
Warranty
5 years
