- Connect legacy mixers and consoles to a Dante network
- Patch DSPs, analog compressors and equalizers into a Dante system using a combination of Dante AVIO Input and Output adapters
- Connect stage DI boxes and keyboard instruments directly to a Dante network
Specifications
- Two channels balanced line level analog input
- Adjustable signal levels: +24dBu / +4dBu / 0dBu/ 0dBV /-10dBV (through Dante Controller)
- Frequency Response: 20Hz to 20kHz (-/+0.5dB)
- Impedance: 20k Ohm balanced, 10k Ohm unbalanced
- Dynamic Range > 100dB
- Signal to Noise Ratio: > 100dB
- Total Harmonic Distortion: < 0.01% at +4dBu
- Sample Rates: 44.1, 48, 96 kHz
- Bit Depth: 24
- Powered through Class 1 802.3af PoE Switch or injector
Packaging info
- Packaging size
- 150 x 150 x 100 mm
- Packaging weight
- 200 g
