Frequency Range (-10dB): 42Hz – 20kHz
Frequency Response (+/-3dB): 56Hz – 20kHz
Maximum Peak SPL: 90 dB-SPL at 1m (0 dBV input , Max Volume setting, one channel) 94 dB-SPL at 1m (both channels driven)
Input Connectors: 2 x RCA (left & , right)
Nominal Input Sensitivity: -10 dBV for 85 dB-SPL at 1m (Max Volume setting)
HF Driver: 2 x 19 mm (0.75”) Soft Dome Tweeter (one per channel)
LF Driver: 4 x 51 mm (2.0”) Low-Frequency Driver (two per channel)
Power Amp: 20W per Channel, Class D
Enclosure Material: Injection-Molded ABS
Enclosure Finish: Black
Mounting/Installation: Two included brackets, desk/table or on-wall mounting.
Dimensions (H x W x D): 90 x 900 x 65 mm (3.54 x 35.4 x 2.55 in). See Owner’s Manual for dimensional drawing.
Weight: 1.8kg (4.0lbs)
Shipping Weight: 2.5kg (5.5lbs)
General
- Application
- Soundbar
- Active/Passive
- Active
- Color
- Black
Speaker drivers
- LF
- 2 " x4
- HF
- 0.75 " x2
Audio specifications
- Frequency range Min
- 42 Hz (-10dB)
- Frequency range Max
- 20,000 Hz (-10dB)
- Amplifier power
- 20 W x2 (Class D)
- Max SPL
- 94 dB @ 1m (both channels driven)
Connections
- Audio inputs
- RCA x2 (L&R) Stereo
Dimensions and weight
- Width
- 900 mm
- Depth
- 65 mm
- Height
- 90 mm
- Net weight
- 1.8 kg
Packaging info
- Packaging size
- 960 x 160 x 130 mm
- Packaging weight
- 2.72 kg
Packaging info (6 pcs)
- Packaging size
- 310 x 410 x 970 mm
- Packaging weight
- 16.50 kg
