An aesthetic solution that adds stability to locations where the ceiling or wall aren't able to support an installation.
Provides the advantages of Fusion ceiling mounts in a floor-to-ceiling form.
Larger clamp clearance area requires less precision when cutting pipe for an easier installation.
Key Features
- 227kg of capacity per pole
- Support displays in portrait or landscape orientation
- Can use stacking displays
- Can use Fusion ceiling single displays or back-to-back mounts
- Use with CPA or CMS columns (CPAE in the EMEA region)
- Can use at floor and ceiling for floor-load-bearing assemblies
- Use standard ceiling plate at ceiling for ceiling-load-bearing assemblies
General
- Mounting solution
- Floor-ceiling
- Column installation
- NPT Threaded, Pin Connection
- Color
- Black
- Angled Ceiling
- No
Measurement and weight
- Max weight capacity
- 227 kg
- Width
- 206 mm
- Height
- 130 mm
- Depth
- 134 mm
Additional information
- Warranty
- 10 years
Packaging info
- Packaging size
- 381 x 216 x 229 mm
- Packaging weight
- 3.90 kg
