Monitor your power anytime, anywhere, and even automatically. Select Series PDUs with RackLink™ creates a simple and cost-effective solution that puts intelligent control of power distribution at your fingertips, wherever you are. The applications are endless - RackLink™ allows you to manage everything from a network of digital signage installs, to a building full of conference rooms, to an entire campus of classrooms - all from your device. Plug it in, feel confident, and simply focus on creating an amazing AV experience.
RackLink™ Select Features & Benefits
- 10 Amps
- 100 – 240V
- 9 Outlets, 8 controlled rear distribution outlets PLUS one front convenience outlet.
- RackLink is international. CE Rated with IEC outlets. Get the RackLink you know and trust for your international deployments.
- The control you need to maintain the uptime of your equipment. After you go through the easy set-up of the RackLink™ user interface, you’ll have individual IP outlet control for up to 8 outlets.
- Manage the start-up or shut down of your equipment. RackLink™ enables remote sequencing with user selectable delays for an optimal start-up or shut down progression.
- Fast and easy commissioning. Using the RackLink™ Discovery app on iPhone or Android, quickly connect your RackLink™ enabled PDUs and monitor your system, anywhere, anytime.
- Automate it and fugetaboutit. Improve your system reliability by automating actions such as multiple IP AutoPing and recovery.
- Always be informed. Receive automatic notifications of connection status.
- Do you prefer to use a third party software? Seamlessly interfaces with 3rd party AV control systems and cloud platforms for scheduling, control, reporting and even customization.
Connection
- Power connection from
- IEC C14 (Appliance)
- Power connection to
- IEC C13 (Appliance)
- No. of sockets
- 9 x
Functions
- Control
- Ethernet/IP (RJ-45), Mobile App, Web interface
Measurements and weight
- Width
- 440.9 mm
- Depth
- 245.6 mm
- Height
- 44.3 mm
- Cable lenght
- 2.74 m
Electric specifications
- Voltage
- 240 Volt to 100V
- Current rating
- 10 Ampere
Additional information
- Warranty
- 3 years
Packaging info
- Packaging size
- 108 x 556 x 342 mm
- Packaging weight
- 4.31 kg
