Superb Picture Quality with Ultra HD Resolution
With the resolution of UHD, it makes the color and details of the contents vivid and realistic. In addition, the wide viewing angle applied with an IPS panel, provides clear contents.

Key Features:

  • Brightness(Typ.) : 330 nits
  • Resolution : ULTRA HD (3,840 x 2,160)
  • webOS-based High Performance
  • Built-in Speaker
  • Compatible with LG's One:Quick Share
  • Compatible with AV Control Systems

LG’s Wireless Screen Sharing Solution, LG One:Quick Share
LG One:Quick Share is a wireless screen sharing solution available through the UL3J series, USB transmission unit, and its app. You can simply share personal PC screen to the display with it's USB dongle button and embedded Wi-Fi*, and can adjust the basic setting values (volume, picture mode, auto bright, etc.) of the connected display without a remote control. Also, the Office Meeting Mode** helps you to display the agenda, note before the meeting starts.
** Users need to set up Soft AP enabled at Network Menu of the Signage.
** Users can enable Office Meeting Mode at EZ Setting Menu of the Signage.
*** LG One:Quick Share needs to be purchased separately.*

Remote Monitoring and Control
This web-based monitoring solution is user-friendly and allows the user to be at ease. It enables the user to have full access anywhere at anytime from their mobile phone & PC under network-accessible environment while having access to both current and past data. It allows the user to monitor the unit, make adjustments and control the unit remotely in real time.

Compatible with AV Control Systems
The UL3J series supports Crestron Connected®* for high compatibility with professional AV controls to achieve seamless integration and automated control**, boosting business management efficiency.
** Initial setting from display is required for Crestron Connected® compatibility.
** Network based control*

Compatible with Video Conference System
For effective visual meeting, the UL3J series supports its compatibility with Cisco solutions that offers powerful and integrated control* for a smarter video conference.
** Using an HDMI cable connection (HDMI cable is optional)*

Easy Menu Setup for Vertical Needs
UL3J series increases users' convenience by organizing frequently used menus* by industry.
** Pre-set Support Vertical : Corporate / Government / Retail, Meeting room*

Wireless Access Point
UL3J series operates as a virtual router which can be an wireless access point for mobile devices.

Superb Picture Quality with Ultra HD Resolution
With the resolution of UHD, it makes the color and details of the contents vivid and realistic. In addition, the wide viewing angle applied with an IPS panel, provides clear contents.

Sophisticated Slim Design
This series is thin in bezel size and thickness*, which saves space and enables easy installation. In addition, it increases the immersive experience from the screen and provides a sophisticated design, improving the décor of the space where the product is installed.
** Compared to LG's UL3G series*

High Performance with LG webOS 6.0
LG webOS 6.0, upgraded in SoC and web engine, is available on UL3J series for a smooth execution of several tasks. LG webOS smart signage platform enhances user convenience with intuitive GUI.

Various Sensor Connection
LG webOS smart signage platform helps to easily provide value-added solutions* by supporting simple connections with external sensors** such as GPIO, NFC/RFID, temperature sensors, etc., via USB plug-in.
** e.g. showing specific promotional information according to weather change to store visitors
** External sensors need to be purchased separately and tested for compatibility with webOS platform.*



Display

Operating Hours
16/7
Image diagonal
75 "
Resolution
3840x2160
Brightness
330 Nits
Portrait
Yes

Functions

Protective Glass
No
Videowall
No
Outdoor use
No
TV Tuner
No
Built-in speaker
Yes
Mediaplayer
Integrated WebOS 6.0
Mediaplayer
USB mediaplayer

Communication

Ethernet
Yes
Wi-Fi
Built-in
Wireless image sharing
Yes via Quick Share

Energy

Power Supply
AC 100 - 240 V ~, 50 / 60 Hz, built in power supply
Consumption Typical
155 W
Consumption Max
220 W

Dimensions and weight

VESA mount interface (mm)
400x400
Width
1,678 mm
Height
964 mm
Depth
59.9 mm
Net weight
31.4 kg

Additional information

Included Accessories
Remote Controller, 2x battery, Power Cord, Regulation Book, Phone to D-Sub9 Gender, Cable Holder
Warranty
3 years swap

Packaging info

Packaging size
1,820 x 1,115 x 200 mm
Packaging weight
34.60 kg
